Rugged & Durable Truss for Live Events, Exhibitions & Retail
The ProX 10'x20' Goal Post XTP-PGP1 F34 Square Truss Package is a convenient all-in-one goal post/finish line truss kit that makes it easy to hang accessories like lighting, screens, speakers, signage, time clocks, LCD panels and announcer sound systems. This kit is easy to assemble in minutes by 2-3 people.
With an overall footprint of 6m (19.68 feet) wide, this kit measures is 3m (9.84 feet) tall when fully assembled. Truss segments measure 290mm (11.4-inch) square and are completely modular, allowing for easy expansion or replacement of parts. Constructed of high-grade aluminium, ProX F34 Square Box Truss consists of a 50x2mm main tubes and 20x2mm braces.
Measurements:
(cross-section)
ProX trussing is TÜV-certified, which recognizes reliability, safety & high quality. ProX trussing utilizes industry standard dimensions to be compatible with and connect to many other manufacturers' F34 trussing products with conical connectors, including Global Truss, ProFlex Truss, Euro Truss and Chauvet Truss.
ProX also manufactures a comprehensive selection of trussing accessories including clamps, hanging & lifting points, spacers, box corners, mounting poles, base/top plates and much more to complete your ideas and make your design an impressive rigging project or a simple show booth. Always consult an engineer for complex designs!
Important
Always know your load weight for your equipment: F34 Truss Loading Chart
Rugged & Durable Truss for Live Events, Exhibitions & Retail
The ProX 10'x20' Goal Post XTP-PGP1 F34 Square Truss Package is a convenient all-in-one goal post/finish line truss kit that makes it easy to hang accessories like lighting, screens, speakers, signage, time clocks, LCD panels and announcer sound systems. This kit is easy to assemble in minutes by 2-3 people.
With an overall footprint of 6m (19.68 feet) wide, this kit measures is 3m (9.84 feet) tall when fully assembled. Truss segments measure 290mm (11.4-inch) square and are completely modular, allowing for easy expansion or replacement of parts. Constructed of high-grade aluminium, ProX F34 Square Box Truss consists of a 50x2mm main tubes and 20x2mm braces.
Measurements:
(cross-section)
ProX trussing is TÜV-certified, which recognizes reliability, safety & high quality. ProX trussing utilizes industry standard dimensions to be compatible with and connect to many other manufacturers' F34 trussing products with conical connectors, including Global Truss, ProFlex Truss, Euro Truss and Chauvet Truss.
ProX also manufactures a comprehensive selection of trussing accessories including clamps, hanging & lifting points, spacers, box corners, mounting poles, base/top plates and much more to complete your ideas and make your design an impressive rigging project or a simple show booth. Always consult an engineer for complex designs!
Important
Always know your load weight for your equipment: F34 Truss Loading Chart
- Perfect for live outdoor or indoor productions, race day, exhibitions, retail displays & nightclubs
- Ideal truss system for rental, touring and exhibition companies
- Constructed from high-grade aluminum with 50mm (2") diameter outer tubes and 20mm (3/4") diameter braces for superior strength
- Includes connecting hardware
- Manufactured to exacting specifications in ProX's own factory
- TÜV-certified aluminum welding
- 4 - ProX F34 Square Straight Truss Segment 2.5m (XT-SQ820)
- 2 - ProX F34 Square Truss 90-Degree Vertical Corner (XT-SQ164-2W90)
- 2 - ProX 1'x4' Aluminum Base Plate for F34 Square Truss (XT-BP1248A)
- Connecting Hardware
- Dimensions:
- Total Width: 6m (19.68 feet)
- Total Height: 3m (9.84 feet)
- Main Tubes: 50mm (2") diameter, 2mm thickness
- Braces: 20mm (3/4") diameter, 2mm thickness
- Total Weight: 216 lbs (97.9 kg)
- Material: Aluminium EN AW-6082 T6
- Safety Certifications: TÜV certified
- 1-Year Manufacturer Warranty
